| Machine types |
7DFH - 3 or 5 year warranty |
| Form factor |
2U rack |
| Processor |
One or two Intel Xeon 6700P-series or 6500P-series processors (formerly codenamed "Granite Rapids-SP"). Supports processors up to 86 cores and 172 threads, core speeds of up to 4.0 GHz, and TDP ratings of up to 350 W. |
| Chipset |
None. Integrated into the processor |
| Memory |
32 DIMM slots with two processors (16 DIMM slots per processor). Each processor has 8 memory channels, with 2 DIMMs per channel (DPC). 16 DIMM slots with 2 processors when the Compute Complex Neptune Core liquid cooling is used (machine type ). Lenovo TruDDR5 RDIMMs and MRDIMMs are supported. RDIMMs operate at up to 6400 MHz at 1 DPC and up to 5200 MHz at 2 DPC. MRDIMMs are supported up to 8000 MHz at 1PDC. |
| Memory maximum |
Up to 8TB by using 32x 256GB 3DS RDIMMs |
| Memory protection |
ECC, SDDC (for x4-based memory DIMMs), ADDDC (for x4-based memory DIMMs), and memory mirroring. |
| Disk drive bays |
Up to 12x 3.5-inch or 28x 2.5-inch hot-swap drive bays:
- Front bays can be 3.5-inch (8 or 12 bays), or 2.5-inch (8, 16 or 24 bays)
- Rear bays can be 2.5-inch (4 bays)
- Combinations of SAS/SATA, NVMe, or AnyBay (supporting SAS, SATA or NVMe) are available
M.2 support, for OS boot and drive storage support:
- 2x front or rear hot-swap M.2 drive bays, or
- Internal M.2 module supporting up to two M.2 AnyBay bays support SAS, SATA or NVMe drives. NVMe bays only support NVMe drives.
|
| Storage controller |
- Onboard NVMe ports (RAID not supported)
- 12 Gb SAS/SATA non-RAID:
|
| Network interfaces |
Dedicated OCP 3.0 SFF slot with PCIe 5.0 x16 host interface. Supports a variety of 2-port and 4-port adapters with 1GbE, 10GbE and 25GbE network connectivity. One port can optionally be shared with the XClarity Controller 2 (XCC3) management processor for Wake-on-LAN and NC-SI support. |
| PCIe slots |
Up to 8x PCIe 5.0 slots, all full height slots and with rear access, plus a slot dedicated to the OCP adapter. Slot availability is based on riser selection and rear drive bay selection. Slots 4, 5, and 6 (riser 2) require two processors.
Slots are configured using three riser cards. Riser 1 (slots 1-3) and Riser 2 (slots 4-6) are installed in slots in the system board, Riser 3 (slots 7-8) is cabled to ports on the system board.
For 2.5-inch front drive configurations, the server supports the installation of a RAID adapter or HBA in a dedicated area that does not consume any of the PCIe slots. |
| GPU support |
Supports up to 8x single-wide GPUs or up to 4x double-wide GPUs |
| Ports |
Front: 1x USB 3.1 G1 (5 Gb/s) port, 1x USB 2.0 port (also for XCC local management), External diagnostics port, optional VGA port.
Rear: 3x USB 3.1 G1 (5 Gb/s) ports, 1x VGA video port, 1x RJ-45 1GbE systems management port for XCC remote management. Optional DB-9 COM serial port (installs in slot 3).
Internal: 1x USB 3.1 G1 connector for operating system or license key purposes |
| Cooling |
6x (with two processors installed) or 5x (with one processor installed) dual-rotor hot swap 60 mm fans, configuration dependent. Fans are N+1 redundant, tolerating a single-rotor failure. One fan integrated in each power supply. |
| Power supply |
Up to two hot-swap redundant AC power supplies, 80 PLUS Platinum or 80 PLUS Titanium certification. 750 W, 1100 W, 1800 W, 2400 W and 2600W AC options, supporting 220 V AC. 750 W and 1100 W options also support 110V input supply. In China only, all power supply options support 240 V DC. Also available is a 1100W power supply with a -48V DC input. |
| Video |
Embedded graphics with 16 MB memory with 2D hardware accelerator, integrated into the XClarity Controller 2 management controller. Maximum resolution is 1920x1200 32bpp at 60Hz. |
| Hot-swap parts |
Drives, power supplies, and fans. |
| Systems management |
Operator panel with status LEDs. Optional External Diagnostics Handset with LCD display. XClarity Controller 3 (XCC3) embedded management based on the ASPEED AST2600 baseboard management controller (BMC), XClarity Administrator centralized infrastructure delivery, XClarity Integrator plugins, and XClarity Energy Manager centralized server power management. Optional XCC3 Premier to enable remote control functions and other features. |
| Security features |
Chassis intrusion switch, Power-on password, administrator's password, Root of Trust module supporting TPM 2.0 and Platform Firmware Resiliency (PFR). Optional lockable front security bezel. |
| Software |
- Azure Local OS preloaded
- Windows Server 2025 Datacenter optional
|
| Hardware warranty |
Three-, four-, or five-year customer-replaceable unit and onsite limited hardware warranty with ThinkAgile Premier Support and selectable service levels: 9x5 next business day (NBD) parts delivered, 9x5 NBD onsite response, 24x7 coverage with 2-hour or 4-hour onsite response, or 6-hour or 24-hour committed repair (select areas). |
| Software maintenance |
Three-, four-, or five-year software support and subscription (matches the duration of the selected warranty period). |
| Dimensions |
Width: 445 mm (17.5 in.), height: 87 mm (3.4 in.), depth: 796 mm (31.3 in.), 924 mm (36.4 in.) |
| Weight |
Maximum weight: 38.8 kg (85.5 lb) |
