Efficient, Scalable, and Secure Capacity-Optimized All-Flash Storage

Reduce rack space and achieve better energy efficiency compared to traditional hybrid flash arrays.
Maximize storage density and efficiency to accelerate data modernization and consolidation.
Unified data management support across different storage media and protocols, on-premises or in the cloud.
Keep data safe with always-on encryption and AI-enhanced autonomous ransomware protection.

Be the first to review “ThinkSystem DG7200 All-Flash Array”

Reviews

There are no reviews yet.

(0)

5 stars

4 stars

3 stars

2 stars

1 stars

No reviews yet.

Specs	Details
NAS Scale-out Maximum	4 HA Pairs/Systems
SAN Scale-out Maximum	4 HA Pairs/Systems
Maximum SSDs	Up to 120 SSDs
Maximum Raw Capacity	Up to 7.4 PB
Maximum Usable Capacity	Up to 5.4 PiB
Maximum Effective Capacity	Up to 27 PiB (based on 5:1)
Controller Form Factor	2U24
PCIe Expansion Slots	Up to 8 expansion slots
FC Target Ports (64Gb)	24, autoranging
FC Target Ports (32Gb)	24, autoranging
FC Target Ports (16Gb)	24, autoranging
100GbE Ports	16, 40GbE autoranging*
25GbE Ports	24, 10GbE autoranging
10GbE Ports	24
10Gbase-T Ports	24, 1GbE autoranging
Storage Networking Supported	NVMe/TCP, NVMe/FC, FC, iSCSI, NFS, pNFS, CIFS/SMB, S3
OS Version	9.16.1 or later
Shelves	DG242N
Host/Client OS Supported	Windows Server, Linux, VMware
Configuration	Per-system specifications; high-availability dual-controller HA pair
Port Reservation	Some ports are reserved for Cluster Interconnect
Expansion Impact	Disk expansion will reduce available host ports

ThinkSystem DG7200 All-Flash Array
